Product Details:
|
| Product Name: | Hydrostatic Top Quality Hdpe Pipe Termofusion Welding Plastic Butt Welding Machine SHT800-SHY Manufactures | Pipe Size: | 630, 710, 800 |
|---|---|---|---|
| Heating Plate Max. Temp: | 270℃ | Total Power: | 16.2 Kw |
| Weight: | 181kg | Frame Packing: | 1900*1360*1400mm |
| Heating Plate Packing: | 1100*720*1620mm | Control Box Packing: | 790*560*510mm |
| G.W./N.W.:: | 1200 Kgs | Heating Plate Power: | 12.5 Kw |
| High Light: | Hdpe Pipe Plastic Butt Welding Machine,Termofusion Butt Welding Machine,12.5 Kw Butt Welding Machine |
||
hydrostatic Top quality hdpe pipe termofusion welding plastic butt welding machine SHT800-SHY manufactures
Place the pipe to be welded in the frame slip, so that the length of both ends is equal (as short as possible without affecting the milling and heating),which can be improved by adjusting the straightness and the elastic slip of the pipe; the gap between the two ends of the pipe should not exceed 10% of the wall thickness, otherwise it should be milled again until the above requirements are met.
Butt Fushion Welding Machine Technical data:
| SHT800 -SHY |
Working Range | |
| Caliber (mm) | 630, 710, 800 | |
| Heating board max temp. | 270 °C | |
| Temperature bias | “+/-5° | |
| Pressure adjustment range | 0-10Mpa | |
| Heating plate power | 12.5 Kw | |
| Power of Heating plate: | 2.2 Kw | |
| Hydraulic unit power | 1.5 Kw | |
| Total power | 16.2 Kw | |
| G.W./N.W.: | 1200 Kgs | |
| Packing size: | 190*136*140cm | |
| 110*72*162cm | ||
| 79*56*51cm |
Service
HAITAO not only supplies reliable, durable and professional tools but we also aim to provide an excellent service to installers.
We offer a range of spare parts available for many products.
If you require spare parts.
Our service:
1) We offer 1 year warranty and free spare parts. (Except for wearing parts)
2) We offer voltage and frequency of motor customization service, such as 110v 60hz.
3) We can put your LOGO on machine plate or packing (need your authorization on brand)
4) Machine can be shipped to overseas or domestic place by sea or air in LCL or FCL.
